Identificador: 290
Abierta
Descripción
PARTE: 2TA-VC-DR07 – BOMBA DE VACIO – 7.5 HP - DRY ROTARY VANE
(VC-DR07) Dry Rotary Vane Type Vacuum Pump
Single stage rotary vane vacuum pump are directly connected the outer covers of aluminum alloy pump with the electrical motor, for efficient and heat dissipation.
The pump are advanced in stable functioning and low noise for acquiring High vacuum pressure, high water vapor tolerance
Dry operation for oil-less and direct drive with no belts or gears to ensure low energy consumption usage
Compact construction, light weight, low noise.
Equipped with the suction filter and exhales muffle, with large filter area and quick change lock for easy maintenance
TEFC motor
Specification | VC-RT15 | VC-DR07 |
Max. Pressure (in. Hg) | 13 | 25 |
Max. Capacity (CFM) | 459 | 177 |
Speed (RPM) | 3650 | 1420 |
Motor Power | 15 HP | 7.5 HP |
Inlet size | 2" | 2" |
Weight (lbs) | 680 | 350 |
Machine Size | 56" x 29" x 58" | 38" x 23" x 19" |
Pago y Devoluciones
- Forma de pago
- Visa/Mastercard/American Express
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
PARTE: AMX-10159 - EXTRACTOR DE TUBO - DIAMETRO INTERNO 15-3/4” - MOTOR 3/4 HP
PARTE: AMX-10159 - EXTRACTOR DE TUBO - DIAMETRO INTERNO
15-3/4” - MOTOR 3/4 HP
USADO - MUY BUENAS CONDICIONES
MOTOR 3/4 HP, 220/440V, 3 FASES,
1750 RPM, SIEMMENS
DIAMETRO INTERNO: 15-3/4”
DIAMETRO EXTERNO: 18”
MEDIDAS TOTALES: 25” LARGO X 13”
ANCHO X 18” ALTO
TODOS LOS 4 BALEROS NUEVOS
AMXmachinery
PARTE: 11787 – LIJADORA DE CEPILLOS Y DISCOS - TIMESAVERS
PARTE: 11787 – LIJADORA DE CEPILLOS Y DISCOS - TIMESAVERSEn buenas condicionesModelo: 337-6RPRotary polisher has six (6) 1/2HP counter-rotating arbors with fladder-style abrasives.Rotation 12-35 RPM, 2HP variable feed 15-45 FPM on conveyor belt with vacuum bed. (Less vacuum pump unit).36” width capacity. Each arbor/spindle is 12”-long x 2”-diameter, arbor speed 100-1200 RPM, with LED readout on RPM. 0” – 6” motorized part thickness opening.Infeed and outfeed pinch rolls.Wired 460V...
AMXmachinery
PARTE: 12177 - PEGADORA – 16 SECCIONES – HIDRAULICA
PARTE: 12177 - PEGADORA –
16 SECCIONES – HIDRAULICA
USADA
– EN BUENAS CONDICIONES
AMXmachinery
PARTE: 12474 - PINCH ROLLER - EVANS
PARTE: 12474 - PINCH
ROLLER - EVANS
USADA - BUENAS CONDICIONES
Safety Gates on In-Feed and Out-Feed
Solid Top and Bottom Rollers
Feed Rate: 50’ FPM
Maximum Width: 62”
Maximum Thickness: 2”
Thickness adjustable by spacers
Work Height: 30-1/2”
Drive Motor: 1/2 HP
Electrical: 120 V, 1 PH,
60 Hz
Air Requirement: 100 PSI
